New style automatic mustard oil machine | sesame oil pressing machine | hydraulic oil press machine

The quality of oil press machine is main factor for oil yield.

Description



1.Instruction of Oil Press Machine:

The quality of oil press machine is main factor for oil yield.There are many elements related to oil yield.As to oil press machine, the main factors are pressure and temperature of chest.The old one adopt round row and space between oil lines is 1.5mm , and it reduce pressure of chest and oil yield.However , as for our machine ,it is 0.25 mm. It adopt electronic temperature control technology to guarantee the best temperature of chest oil yield .What’s more,different materials have different request to temperature, and the system can control that in time.The most important is that we can ensure capacity is 1.5-2kg more comparing with other machines.
We have strict quality request to our machine , please believe our oil press machine with best design and high quality.



2.Application of Oil Press Machine:

Applied for oil extracting from various oilseeds include: soybean, sunflower seeds, peanut, rapeseeds,

cottonseeds, vegetable seeds, mustard  seed, copra, canola, flax seed, castor seeds, tea seed, corn embryo etc.



3.Main Technical Parameters of Oil Press Machine:

Model QXLX-80 QXLX-100 QXLX-130
Diameter of worm shaft (mm) Φ80 Φ100 Φ128
Speed of worm shaft (r/min) 35 37 34
Diameter of internal circle of pressing chest (mm) Φ82 Φ102 Φ130
Equipped with power Main engine Y-132-M2-6
4-4.5KW
Y-132M-4
7.5KW
Y-160M-6
15.5KW
Vacuum pump  Y801-4
0.55KW
Y-802-4
1.1KW
Y90S-4
1.1KW
Heater 2.2KW 2.2KW 4.2KW
Capacity (kg/h) 80-100 150-200 300-400
Weight of the whole machine (kg) 780 1100 15000
Dimension (L*W*H) (mm) 1600X1100X1550 1800X1100X1550 2200X1480X2100
